Get Strong And Durable 8x10cm Gabion Mattress From Our Factory

Specifications: (1)Hole size: 60 * 80mm, 80 * 100mm, 80 * 120mm, 100 * 120mm, 120 * 150mm (2) Wire:mesh wire, edge wire, and binding wire (3) wire tension: no less than 38kg/m2 380N/mm (4) surface treatment 1. Electrogalvanizing.The maximum amount of zinc is 10g/m2.Anticorrosion sex difference 2. Hot galvanizing.The maximum amount of zinc can reach 300g/m2.Strong anticorrosion 3. Galfan (zinc aluminum alloy).It is divided into two materials: zinc-5% aluminum - mixed rare earth alloy wire, zinc - 10% aluminum mixed rare earth alloy wire.Superprotective strength 4. PVC plastic coated.The thickness of the package is usually 1.0mm thick, for example: 2.7mm and 3.7mm. (5) partition: add a partition to each meter in the long direction of the cage net (6) size: can be customized (7) the range of aperture and silk diameter.

SPECIFICATIONS
Gabion Boxes 80x100mm 100x120mm 120x150mm	Mesh Wire Dia.	2.70mm	Zinc coating: >260g/m2
	Edge Wire Dia.	3.40mm	Zinc coating: >275g/m2
	Tie Wire Dia.	2.20mm	Zinc coating: >240g/m2
Mattress 60x80mm	Mesh Wire Dia.	2.20mm	Zinc coating: >240g/m2
	Edge Wire Dia.	2.70mm	Zinc coating: >260g/m2
	Tie Wire Dia.	2.20mm	Zinc coating: >240g/m2
Special sizes are available.	Mesh Wire Dia.	2.00~4.00mm
	Edge Wire Dia.	2.70~4.00mm
	Tie Wire Dia.	2.00~2.20mm

QC Process: 1.zinc coated:when mattriail arriving our workshop,QA engineer will select wire randomly,then decet them in our lab. 2.Wire diameter:use micrometer to test,0.05mm tolrrance is acceptable. 3.Size:we will measure L W H according customer order. On the other way if there is any specifications wrong we can correct it immediately save more time ensure the shippment we promised.

Package

The gabion box package is folded and in bundles or in rolls. We also can pack it according to customers special request.

8x10cm Gabion Mattress
